Homogenizing & Emulsifying Machine
Efficient Lab-Scale Homogenizer for Precise Mixing and Dispersion
- Product Introduction
Products Description
The KR-500 is a compact, versatile lab-scale homogenizing and emulsifying system designed for rapid sample processing. With speeds up to 30,000 rpm, it delivers efficient dispersion, homogenization, and emulsification across a wide range of liquid and semi-solid materials.
Engineered with an imported high-speed motor, stepless speed control, and quick-change blade system, it is ideal for both routine and demanding lab applications.
- Max Speed: 30,000 rpm
- Capacity: 0.2 – 7,000 mL
- Stepless 6-level speed adjustment
- Acid, alkali, and heat-resistant stainless steel cutter head
Application
Suitable for industries such as:
- Biopharmaceuticals & Life Sciences – tissue disruption, cell lysis, DNA/RNA prep
- Food & Dairy – emulsification, homogenization, ingredient blending
- Cosmetics & Personal Care – lotions, creams, serums, suspensions
- Nanomaterials & Polymers – fine dispersion and reaction assistance
- Environmental & Energy – sample pretreatment, mixing for analytical testing
- Inks, Paints, Pesticides – fine chemicals and fluid blending
Key Features
- Imported Motor: Quiet, long-life, and stable
- Tool-Free Blade Change: Quick and easy to dismantle
- Adjustable Stand: Smooth lifting with lock function
- Six-Speed Stepless Control: Fine-tuned mixing control
- 316 Stainless Steel Cutter Head: Corrosion & high-temp resistant
- Max Speed up to 30,000 rpm: Achieve uniform dispersion in seconds
paramenters of CRA series
Expedite multifunctional data after next-generation solutions done foster extensible total linkage after enterprise methodologies never enable resource maximizing relationships
| product |
 |
| Model | KR-500 |
|
Model |
KR-500 |
|
Voltage |
220V, 50–60Hz |
|
Motor Power |
500W |
|
Speed Range |
8,000 – 30,000 rpm |
|
Speed Control |
Stepless (6-gear) |
|
Display |
Analog Scale |
|
Processing Volume |
0.2 – 7,000 mL |
|
Cutter Head Material |
316 Stainless Steel |
| General purpose I/O | IEC 61076-2-104 |
|
Shaft Sleeve |
PTFE |
|
Max Working Temp |
≤ 120°C |
|
Operating Conditions |
Temp: 5–40°C / RH: ≤80% |
|
Dimensions |
275 × Φ65 mm |
|
Net Weight |
3 kg (main unit only) |
Standard Working Head
|
Model |
Volume (mL) |
Viscosity |
Rotor Speed |
|---|---|---|---|
|
KR500-25G-P |
100–7000 |
5000 cP |
27 m/s |
|
KR500-20G-P |
50–1500 |
3000 cP |
19 m/s |
|
KR500-18G-P |
50–1500 |
3000 cP |
19 m/s |
More head sizes available upon request.
💡 Why Choose KR-500?
🧪 Ideal for R&D, lab-scale production, and pilot lines
🔁 Compatible with a wide range of vessels and materials
💰 Competitive pricing with premium-grade motor and components
🌐 OEM/ODM available for distributors and private labeling
